Blowing Filling Capping System PET Bottle Blow Molding Machine
Integrated Blowing Filling Capping System
Integrated bottle cap system is a new generation of beverage
production line developed by our company. It combines the functions
of a PET bottle blowing machine, a liquid filling machine and a
bottle cap machine. The machine can effectively save the process of
intermediate material transfer, empty bottle handling, storage and
so on.
Technical Parameters of Integrated Blowing Filling Capping System
Number of Bottle Feed Cavity | 16 |
Number of Filling Head | 40 |
Number of Capping Head | 12 |
Productivity | 24,000 BPH (500ml) |
Applicable Bottle | Dia.: Φ60-Φ90, height: 180-260 |
Overall Dimension | 13,100×7,780×3,840 (L×W×H) |
Main Motor Power | 5.5+7.5kW |
Weight | 25,000kg |
Note:
1. The production capacity is based on bottles of 500ml. The actual
capacity may be affected by the size and shape of customers'
bottles.
2. Best Crown reserves the right to change these data according to
the specific conditions.
Technical features:
Non-contact imported electronic flowmeter filling system and
mechanical valve fixed liquid level filling valve to ensure
accuracy.
Customer-customized full servo stretching system to meet various
stretch ratios.
Complete and fully automatic CIP system to ensure the sanitary
requirements of the inner surface of the equipment.
Adopt PROFIBUS intelligent control technology to realize whole line
control and intelligent data report, each Real-time monitoring of
links.
